JE-Pistons Kit SV650 ’99-10 + DL650 ’04-11 13.0:1 83mm
368,14 €
2 em stock
Informação adicional
| Brands | JE |
|---|---|
| Grupo | Pistons |
| Marca Veículo | Suzuki |
| Modelo Veículo | DL 650 V-Strom, SV 650 |
| Ano | 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011 |
| Additional Info | 4 Valve Pockets, Forged Piston |
| Bore - Actual | 83.00 mm |
| Bore - Oversize | 2.00 mm |
| Compression Ratio - Actual | 13.0:1 |
| Country of Origin | USA |
| Displacement | 677 cc |
| GTIN | 00193564220493 |
| Image Info | These images are representative |
| Package Height | 139,00 mm |
| Package Length | 276,00 mm |
| Package Weight | 896.00 g |
| Package Width | 149,00 mm |
| Skirt Type | FSR |
| Weight - Nominal | 224 g |
| Bore - Standard | 81.00 mm |
| Compression Ratio - Over Stock | +1.5 |
| Total Height | mm |
| Piston Pin Hole Diameter | 20.00 mm |
| Compression Height | mm |
| Boss Space In | mm |
| Piston Head Type | Flat with raised top |
| Skirt Coating | – |
| OEM Reference No | 12111-20F00-0F0 |
| Piston Ring Part # | JE-XC8300 |
| Piston Pin Part # | JE-787-2050-10-93C |
| Circlip Part # | JE-787-050-MW |
